RALTRON RH100-12.000-12-1010-X-TR-NS1  3225  12M 12PF 10ppm晶振
美國Raltron電子公司于1983年在佛羅里達州邁阿密成立,現已發展成為世界上最受認可和經驗豐富的頻率管理產品制造商之一.從簡單的音叉晶體到高穩定性的恒溫箱控制晶體振蕩器,拉隆晶振Raltron提供業內最全面的頻率管理設備系列.
多年來公司對研發的承諾使領先的晶體和振蕩器器件和技術得以不斷創造.Raltron提供高性能的頻率控制解決方案,在價格,質量,應用和客戶支持方面滿足并超越客戶的期望.為了滿足快速增長的無線應用市場的需求,Raltron還將自己定位為完整的解決方案供應商,在其晶體和振蕩器產品中增加了SAW器件和LTCC濾波器.該公司還為同一市場開發了完整的天線產品系列.
美國RALTRON晶振,拉隆貼片晶振,RH100-12.000-12-1010-X-TR-NS1無源晶振

Raltron通過獨立的銷售代表的全球網絡以及亞洲的幾個子公司來支持其全球客戶,這些辦事處戰略性地靠近主要客戶和市場.該公司的產品由幾家大型全球分銷商、著名的高服務分銷商以及針對特定市場的區域分銷商分銷.
Raltron正在佛羅里達州邁阿密的工廠開發和制造精密振蕩器,而簡單的晶體
諧振器,時鐘振蕩器和濾波器以及天線則在亞洲的幾家石英晶振工廠生產.該公司正在從其位于香港的物流中心向全球運送產品.
所有Raltron員工都致力于不斷追求質量和卓越.這一理念使Raltron在多年不間斷的增長中一直處于領先地位.位于佛羅里達和亞洲的兩個應用工程團隊確保從客戶產品開發過程的第一步開始,并在整個客戶的產品生命周期中提供深入的技術支持.這兩個地點還設有配備現代化測試設備的故障分析實驗室,使公司能夠實時響應客戶的請求.
美國RALTRON晶振,拉隆貼片晶振,RH100-12.000-12-1010-X-TR-NS1無源晶振


PARAMETER	VALUE
NOMINAL FREQUENCY	12.000 MHz
MODE OF OSCILLATION	Fundamental
FREQUENCY TOLERANCE AT 25°C	±10 ppm max
FREQUENCY STABILITY OVER TEMPERATURE	±10 ppm max
OPERATING TEMPERATURE RANGE	-40°C to +85°C
STORAGE TEMPERATURE RANGE	-55°C to +125°C
AGING	±3 ppm first year max
LOAD CAPACITANCE	12 pF
EQUIVALENT SERIES RESISTANCE	30  max
SHUNT CAPACITANCE	2 pF max
DRIVE LEVEL	300 µW max
INSULATION RESISTANCE	500 M? min @ DC 100V

Raltron致力于通過將大部分收益投資于深化現有客戶關系,滲透新市場和開發尖端
性能新產品來實現持續增長.
Raltron產品包括：
進口晶振石英晶體范圍從標準微處理器到定制的緊密穩定性和汽車規格,提供通孔和SMD封裝.
晶體時鐘振蕩器提供標準和高頻、低抖動規格.
精密振蕩器,包括VCXO、TCXO、OCXO、VCO和PLL,根據客戶規格設計,以滿足廣泛的電氣和環境要求.
同步模塊為GPS提供完整的定時解決方案電信和廣播網絡的
紀律時鐘同步用于無線應用的
SAW濾波器和諧振器晶體濾波器和陶瓷諧振器采用通孔和表面貼裝封裝,適用于各種消費類應用.
用于無線應用的LTCC濾波器、巴倫和片式天線.
用于無線應用的天線–芯片、有源和無源貼片、偶極子、段、圓頂、PCB、螺旋等.
美國RALTRON晶振,拉隆貼片晶振,RH100-12.000-12-1010-X-TR-NS1無源晶振

晶振編碼參數	頻率	偏差	電壓	溫度	尺寸
	25MHz	±50ppm	3.3V	-40°C to +85°C	7 x 5 x 1.8 mm
CO4305-25.000-EXT-T-TR
Raltron
CO4 Series 25 MHz 3.3 V ±50 ppm -40°C TO +85°C SMT CMOS Clock Oscillator
	25MHz	±50ppm	3.3V	-20°C to +70°C	7 x 5 x 1.8 mm
CO4305-25.000-T-TR
Raltron
CO43 系列 25 MHz 7 x 5 mm 3.3 V ±50 ppm 表面貼裝 時鐘振蕩器
C01100-66.666MHZ
Raltron
CO1 Series 66.666 MHz 20.8 x 13.2 mm 5 V ±100 ppm Through Hole Clock Oscillator
	20MHz	±100ppm	5V	0°C to 70°C	13.21 x 13.21 x 5.1 mm
C019100-20.000
Raltron
CO1 Series 20 MHz 5 V ±100 ppm -20°C TO +70°C Thru-Hole HCMOS Clock Oscillator
	27MHz	±20ppm	3.3V	-40°C to +85°C	7 x 5 x 1.8 mm
C04302-27.000-EXT-T
Raltron
CO43 Series 27 MHz 7 x 5 mm 3.3 V ±20 ppm Surface Mount Clock Oscillator
C04310-32.000-EXT-T-TR
Raltron
CO4 Series 32 MHz 3.3 V ±100 ppm -40°C TO +85°C SMT CMOS Clock Oscillator
	32MHz	±100ppm	3.3V	-40°C to +85°C	7 x 5 x 1.8 mm
C04310-32.000-EXT-TR
Raltron
CO43 Series 32 MHz 7 x 5 mm 3.3 V ±100 ppm Surface Mount Clock Oscillator
	80MHz	±100ppm	3.3V	-10°C to +70°C	7 x 5 x 1.8 mm
C04610-80.000-T-TR
Raltron
CO46 系列 80 MHz 7 x 5 mm 3.3 V ±100 ppm 表面貼裝 時鐘振蕩器
	20MHz	±100ppm	5V	-40°C to +85°C	7 x 5 x 1.8 mm
C04810-20.000MHZ-EXT-TR
Raltron
CO48 Series 20 MHz 7 x 5 mm 5 V ±100 ppm Surface Mount Clock Oscillator
	125MHz	±50ppm	2.5V	0°C to 70°C	7 x 5 x 2 mm
CLDPTSH-125.000
Raltron
Clock Series 125 MHz 2.5V ±50 ppm -0°C TO +70°C SMT LVDS Clock Oscillator
	29.4912MHz	±50ppm	5V	0°C to 70°C	20.8 x 13.2 x 5.1 mm
CO1050-29.4912
Raltron
CO1 Series 29.4912 MHz 20.8 x 13.2 mm 5 V ±50 ppm Through Hole Clock Oscillator
	1.8432MHz	±100ppm	5V	0°C to 70°C	20.8 x 13.2 x 5.1 mm
CO1100-1.8432MHZ
Raltron
CO1 Series 1.8432 MHz 20.8 x 13.2 mm 5 V ±100 ppm Through Hole Clock Oscillator
	11.0592MHz	±100ppm	5V	0°C to 70°C	20.8 x 13.2 x 5.1 mm
CO1100-11.0592MHZ
Raltron
CO1 Series 4.9152 MHz 20.8 x 13.2 mm 5 V ±100 ppm Through Hole Clock Oscillator
	16MHz	±100ppm	5V	-20°C to +70°C	20.8 x 13.2 x 5.1 mm
CO1100-16.000MHZ-T
Raltron
CO1 Series 16 MHz 5 V ±100 ppm -20°C TO +70°C Thru-Hole TTL Clock Oscillator
	18.432MHz	±100ppm	5V	0°C to 70°C	20.8 x 13.2 x 5.1 mm
CO1100-18.432-T
Raltron
CO1 Series 18.432 MHz 5 V ±100 ppm -20°C TO +70°C Thru-Hole TTL Clock Oscillator
	18.432MHz	±100ppm	5V	0°C to 70°C	20.8 x 13.2 x 5.1 mm
CO1100-18.432-T
Raltron
CO1 Series 18.432 MHz 5 V ±100 ppm -20°C TO +70°C Thru-Hole TTL Clock Oscillator
	39.3216MHz	±100ppm	5V	0°C to 70°C	20.8 x 13.2 x 5.1 mm
CO1100-39.3216-T
Raltron
CO1100 系列 39.3216 MHz 100 ppm 0° C至+70° C 時鐘振蕩器
	4.9152MHz	±100ppm	5V	0°C to 70°C	20.8 x 13.2 x 5.1 mm
CO1100-4.9152MHZ
Raltron
CO1 Series 4.9152 MHz 20.8 x 13.2 mm 5 V ±100 ppm Through Hole Clock Oscillator
	4.9152MHz	±100ppm	5V	-20°C to +70°C	20.8 x 13.2 x 5.1 mm
CO1100-4.9152MHZ-40
Raltron
CO1 Series 4.9152 MHz 5 V ±100 ppm -20°C TO +70°C Thru-Hole TTL Clock Oscillator
	40MHz	±100ppm	5V	0°C to 70°C	20.8 x 13.2 x 5.1 mm
CO1100-40.000MHZ
Raltron
CO1 Series 40 MHz 20.8 x 13.2 mm 5 V ±100 ppm Through Hole Clock Oscillator
	7.77773MHz	±100ppm	5V	-40°C to +85°C	20.8 x 13.2 x 5.1 mm
CO1100-7.777728MHZ-40
Raltron
CO1 Series 7.7777 MHz 5 V ±100 ppm -40°C TO +85°C Thru-Hole TTL Clock Oscillator
	70MHz	±100ppm	5V	0°C to 70°C	20.8 x 13.2 x 5.1 mm
CO1100-70.000
Raltron
CO1 Series 70 MHz 20.8 x 13.2 mm 5 V ±100 ppm Through Hole Clock Oscillator
	20MHz	±50ppm	5V	-40°C to +85°C	13.21 x 13.21 x 5.1 mm
CO12050-20.000-EXT
Raltron
CO1 Series 20.00 MHz 5 V ±50 ppm -40°C TO +85°C Thru-Hole HCMOS Clock Oscillator
	20MHz	±50ppm	5V	-40°C to +85°C	13.21 x 13.21 x 5.1 mm
CO12050-20.000-EXT
Raltron
CO1 Series 20.00 MHz 5 V ±50 ppm -40°C TO +85°C Thru-Hole HCMOS Clock Oscillator
	14.3182MHz	±100ppm	5V	0°C to 70°C	13.21 x 13.21 x 5.1 mm
CO12100-14.31818MHZ
Raltron
CO12 Series 14.31818 MHz 13.21x13.21mm 5 V ±100ppm Through Hole Clock Oscillator
	48MHz	±100ppm	5V	-20°C to +70°C	13.21 x 13.21 x 5.1 mm
CO12100-48.000
Raltron
CO1 Series 48.0 MHz 5 V ±100 ppm -20°C TO +70°C Thru-Hole HCMOS Clock Oscillator
